venture Speaker Driver Units
- the Ultimate choose for musical neutral sound -
 音樂性的自然中性聲音極致選擇

比利時


Venture 3" full range

VT-2 Venture 3" 全音域
Overall size: -
Parameter,單體參數
Power(承受功率): 25W
Rdc(直流阻抗): 5.14 Ohm
Sd(錐盆面積): 31.2 cm2
Qm: 2.11
Qes: 0.97
Qts(推動Q值): 0.67
Fs(共響頻率): 122.8 Hz
Vas(推動容積): 1.15 lt
Mms: 2.03 g
Cms: 0.83 mm/N
BL: 2.88
SPL(w/m效率): 85.3 dB
Net Weight(淨重): 0.57kgs

VT-2SR Venture 3" 全音域
Overall size: -
Parameter,單體參數
Power(承受功率): 25W
Rdc(直流阻抗): 4.74 Ohm
Sd(錐盆面積): 32 cm2
Qm: 1.68
Qes: 0.75
Qts(推動Q值): 0.52
Fs(共響頻率): 84.2 Hz
Vas(推動容積): 2.02 lt
Mms: 2.49 g
Rms: 0.8 kg/s
Cms: 1.38 mm/N
BL: 2.91
SPL(效率): 84.2 dB
Net Weight(淨重): 0.57kgs


venture V5 VT-5 Venture 5" Woofer中低音
Overall size: 156mm dia. x 116mm (H)
Parameter,單體參數
Power(承受功率): 100W
Rdc(直流阻抗): 6 Ohm
Sd(錐盆面積): 82 cm2
Qm: 2.75
Qes: 0.47
Qts(推動Q值): 0.4
Fs(共響頻率): 43.5 Hz
Vas(推動容積): 11.5 lt
Mms: 10.9 g
Rms: 1.18 kg/s
Cms: 1.22 mm/N
BL: 5.9
SPL(w/m效率): 85 dB
SPL(2.83v/m效率): 86.2 dB
Net Weight(淨重): 4.45 kgs

Venture V7

VT-7 Venture 7 " Woofer中低音
Overall size: 180mm dia. x 120mm (H)
Parameter,單體參數
Power(承受功率): 100W
Rdc(直流阻抗): 12.4 Ohm
Sd(錐盆面積): 132 cm2
Qm: 4.21
Qes: 0.22
Qts(推動Q值): 0.21
Fs(共響頻率): 22.9 Hz
Vas(推動容積): 73.42 lt
Mms: 16.42 g
Rms: 0.56 kg/s
Cms: 2.95 mm/N
BL: 11.47
SPL(2.83v/m效率): 87 dB
Net Weight(淨重): 2.56 kgs

VT-7SD Venture 7 " Car Woofer汽車用中低音
-- 與上同 -- 但
Rdc(直流阻抗): 4 Ohm


Venture V8 VT-8 Venture 8" Woofer中低音
Overall size: 225mm dia. x 141mm (H)
Parameter,單體參數
Power(承受功率): 150W
Rdc(直流阻抗): 7.26 Ohm
Sd(錐盆面積): 226 cm2
Qm: 3.71
Qes: 0.17
Qts(推動Q值): 0.16
Fs(共響頻率): 18.9 Hz
Vas(推動容積): 160 lt
Mms: 32 g
Rms: 1.18 kg/s
Cms: 2.19 mm/N
BL: 12.8
SPL(2.83v/m效率): 90 dB
Net Weight(淨重): 4.45 kgs

歡迎詢價Venture單體全系列產品
* 以上所列規格為參考值,且如有改變不另外告知
